This product supports UPC/APC fiber end-face grinding, single-mode/multi-mode optical fiber, FC/LC/SC (customizable) and other connector types, which are widely used in the field production and fiber end-face repairing for Mobile, Telecom, Unicom and radio and television FTTH, indoor distribution system, optical fiber wiring system and monitoring system
Send Email Get A QuoteThis product supports UPC/APC fiber end-face grinding, single-mode/multi-mode optical fiber, FC/LC/SC (customizable) and other connector types, which are widely used in the field production and fiber end-face repairing for Mobile, Telecom, Unicom and radio and television FTTH, indoor distribution system, optical fiber wiring system and monitoring system
One key operation, it can complete fiber end-face processing from 30μm to ADS by 1 '10"
On-site customized fiber/drop cable patch cord length, easy maintenance later
Light weight, small size, only 210*130*125mm, shockproof and waterproof, can be carried and back
Data center room maintenance/rectification, 5G room division, integrated wiring, telecom / Optoelectronic FTTH
| Specification Parameter | |||
| Model | HY-90 | ||
| Polishing Mode | SC/FC/LC | End Face Type | UPC/APC |
| Polishing Time | 70s | UV Curing Time | 12S |
| Repairing Time | 39s | Abrasive Paper Life | 30+ |
| Return Loss | ≥45dB | Insert Loss | ≤0.3dB |
| Magnification Times | 252 times | Working Temperature | -10℃～50℃ |
| Battery Capacity | 3400mAh+7800mAh | ||
| Charger Input Voltage | 100V-240VAC 50/60Hz 1.5A | Charger Output Voltage | DC12.6v |
| Net Water Tank Volume | 30ml | Sewage Tank Volume | 25ml |
| Display Screen Size | 70mm*53mm | Screen Resolution | 340*240 |
| Weight | 2.3kg | Dimension | 209mm*123mm*104mm |
| Stardard Configuraitons | |||
| HY-90 Polishing Machine | 1 set | Adapter | 1 piece |
| SC-UPC Clamp | 1 piece | Multi-function fiber stripper | 1 piece |
| LC-UPC Clamp | 1 piece | UV Lamp | 1 piece |
| FC-UPC Clamp | 1 piece | Cutter Pen | 1 piece |
| Water Pipe | 1 piece | Alcohol Pump | 1 piece |
| Power Bank | 1 piece | Water Bottle | 1 piece |
| Bag | 1 piece | User Manual | 1 piece |
| Abrasive Paper | 1 set | Rubber Mat | 1 piece |
